Think about your needs. Do you have to server hundreds of movies to multiple independent PCs throughout a house, or do you just need a convenient place to put your music to play on your HTPC? The use of a home fileserver will strongly guide the next steps.
Think about storage space. How much do you need? This is also tied closely to the last question. If all you have is a couple HD movies (or many DVD-quality movies) and a bit of music, you could probably get away with a single 500 GB drive. For many HD movies, a large music collection, and lots of family photos, a larger hard drive or an array of many hard drives may be better suited.
Think about multiple drives/RAID arrays. If you decided you need a lot of space in the previous step, a RAID array might be what is needed.
Decide about RAID level. RAID 1 mirrors the content in all disks, offering the most reliability with capacity of the single disk only. For less paranoid, RAID 6 tolerates as much as two disk failures without data loss. RAID 5 gives the most capacity (just one disk less than total number of disks). RAID 10 provides the most performance, offering half of the capacity. Finally, RAID 0 is fastest but loses data in all disks after any single disk fails, so is generally not a good choice if you have no other backup source. Not all levels are possible with any number of disks - usually the more disks, the more choices you have. There are also more levels - read up on the standard RAID levels on a web.
Think about a RAID controller. Hardware controllers are fast, reliable, easy to install and offer wider choice of possible RAID configurations. However they are not cheap and if your motherboard has enough hard drive ports you can also try software RAID without controller. It will outperform the cheapest hardware RAID cards. However you need to search the web for setup instructions and likely use Linux. You may also save money by using software RAID with non-RAID controller that usually will be bundled with all required software.
Think about the rest of the PC. A fileserver tends to require little power, so a budget CPU + motherboard is usually sufficient. Ensure it has a slot (usually PCI-Express) for the RAID card if applicable. 1-2GB of RAM is often enough, unless the server will also be running applications. Gigabit Ethernet allows for future expansion and high speeds when loading content from the server. A power supply needs to provide enough power for all your hard drives. The 3.5' drives vary in power consumption from 7W till as many as 25W so search the web for the precise model you have.
Think about a case. Will this server be in a rack, or just in a desktop case? The rack enclosure is optimized to stack many servers on a shared rack (it is low, flat and wide). Such rack can be bought but for a single server may not make sense. However if you plan to place your server to some server centre, the "desktop shape" server will be at least way more expensive to house, if accepted at all.
Build! Airflow is especially important in servers, as hot spots can easily develop when many hard drives are running continuously. Ensure there are enough fans, that they blow the air in a straight path from front to back, and that they all work. A dead fan can cause a lot of headaches later! Don't skimp here.
Install an OS and software. Linux is usually a solid choice. Any Linux server distro should work fine and get you up and running quickly. Alternatively, Windows Server OSes are very configurable, but require significantly more power and resources. Finally, Windows Home Server is a new kid on the block, but it has many powerful features. With WHS, you don't need a RAID card or any sort of controller to create a large array, but be aware if the OS dies, so does all your data with it.
